BIM Compiler User Guide¶

Foundation: BBC · DATA_MODEL · BIM_COBOL · MANIFESTO · TestArchitecture

Version: 1.1.0 Updated: March 2026

Table of Contents¶

Quick Start
Building and Running
DSL Syntax Reference
Available Room Types
BOM Resolution
LOD400 Library Integration
Profiles and Building Codes
Fire Protection
Output Formats
Material and Colour Data
Validation and Proofs
Spatial Scoring (X-Ray)
MEP System Queries
Troubleshooting

Quick Start¶

Minimal Example¶

Create a building DSL file (e.g., my_house.bim):

BUILDING "My House" type:SINGLE_UNIT profile:"Malaysian_Residential" {

    GRID {
        axes: A, B, C / 1, 2, 3
        spacing: 4.5, 5.0 / 3.0, 3.5
    }

    STOREY "Ground" level:0 height:2.8m {

        BEDROOM "master" bounds:A1-B2 {
            exterior: west, south
            WINDOW wall:west
        }

        BATHROOM "bath" bounds:B1-C2 {
            WINDOW wall:east
        }

        LIVING "lounge" bounds:A2-C3 {
            exterior: south, east
            WINDOW wall:east
        }
    }

    ROOF pitch:25deg overhang:600mm
}

Compile and Verify¶

# Build from project root
mvn compile -q

# Compile SampleHouse (UK residential)
mvn exec:java -pl DAGCompiler \
  -Dexec.mainClass="com.bim.compiler.dsl.SampleHouseEndToEndTest" -q

# Check spatial fidelity against reference
python3 DAGCompiler/python/spatial_checker.py \
  DAGCompiler/lib/output/ifc4_samplehouse.db \
  DAGCompiler/lib/input/Ifc4_SampleHouse_extracted.db \
  --discipline ARC

Building and Running¶

Prerequisites¶

Java 17+
Maven 3.8+
Python 3.10+ (for spatial checking and extraction scripts)

Build from Source¶

mvn compile -q          # Compile all modules
mvn clean package       # Full build

The Four Buildings¶

The compiler validates against four buildings spanning three construction traditions:

Building	Command Class	Tradition	F1 Score
SampleHouse	`SampleHouseEndToEndTest`	UK residential	100%
Duplex	`TBLKTNDuplexEndToEndTest`	US residential	100%
Terminal	`TerminalEndToEndTest`	MY institutional	~100%
TB-LKTN	`TBLKTNEndToEndTest`	MY affordable	generative

TB-LKTN is the first generative building — compiled purely from relational rules with no IFC reference. It proves the compiler can create, not just replicate.

Run Commands¶

All commands run from project root. The -pl DAGCompiler flag is required.

# SampleHouse (single-storey UK house)
mvn exec:java -pl DAGCompiler \
  -Dexec.mainClass="com.bim.compiler.dsl.SampleHouseEndToEndTest" -q

# Duplex (2-storey US duplex, 1,085 elements)
mvn exec:java -pl DAGCompiler \
  -Dexec.mainClass="com.bim.compiler.dsl.TBLKTNDuplexEndToEndTest" -q

# Terminal (4-storey airport terminal, 51,088 elements)
mvn exec:java -pl DAGCompiler \
  -Dexec.mainClass="com.bim.compiler.dsl.TerminalEndToEndTest" -q

# TB-LKTN (single-storey affordable house, 58 elements)
mvn exec:java -pl DAGCompiler \
  -Dexec.mainClass="com.bim.compiler.dsl.TBLKTNEndToEndTest" -q

Output¶

Each compilation produces: - DAGCompiler/lib/output/*.db — SQLite database with geometry, materials, spatial index - Console output with element counts, witness proofs, and placement diagnostics

DSL Syntax Reference¶

Overall Structure¶

BUILDING "<name>" [type:<template>] [profile:"<profile>"] [compliance:<mode>] {
    GRID { ... }
    STOREY "<name>" level:<z> height:<h> {
        <room declarations>
    }
    ROOF pitch:<degrees> [overhang:<mm>]
}

The DSL is a catalog selector — it declares what the user wants, not how to build it. Room sizes come from the grid, wall types from the profile, furniture from BOM recipes. No coordinates, no geometry.

GRID Definition¶

GRID {
    axes: A, B, C, D, E / 1, 2, 3, 4, 5
    spacing: 1.3, 3.1, 3.7, 3.1 / 2.3, 3.1, 1.5, 1.6
}

Grid axes define structural column lines. Spacings are in meters between consecutive axes. Room bounds reference grid intersections (e.g., bounds:A2-C3 = rectangle from axis A/line 2 to axis C/line 3).

Room/Space Declaration¶

BEDROOM "master" bounds:A2-C3 { ... }
BATHROOM "bath" bounds:B1-C2 { ... }
OPEN_PLAN "common" bounds:B2-D5 { zones: LIVING, DINING, KITCHEN }

Constraint Keywords¶

Keyword	Effect	Example
`exterior: <direction>`	Room has exterior wall on this face	`exterior: south`
`adjacent: <room>`	Shares wall with named room (generates door)	`adjacent: living`
`opens_to: <room>`	Opens to open-plan area (generates door)	`opens_to: common`
`stack: <name>`	Named plumbing stack (groups wet areas)	`stack: plumbing`
`compliance: <mode>`	Fire protection compliance mode	`compliance: AUTO_FP`
`zones: <list>`	Functional zones within OPEN_PLAN	`zones: LIVING, DINING`

OPEN_PLAN (Combined Zones)¶

Combines multiple functional zones without internal walls:

OPEN_PLAN "common" bounds:B2-D5 {
    zones: LIVING, DINING, KITCHEN
    exterior: south
    exterior: north
}

Zones share the space. No walls between them. Perimeter walls only. Fixture placement uses zone types (kitchen gets counter, dining gets table).

Door and Window Specifications¶

DOOR type:D1 size:900x2100 wall:south    // Main entry
DOOR type:D2 size:750x2100               // Bedroom door
WINDOW type:W1 size:1800x1000 wall:west  // Standard window
WINDOW type:W3 size:600x500 wall:east    // Ventilation window

When type codes are omitted, the compiler resolves appropriate families from the profile and room context.

CORE Block (Vertical Circulation)¶

CORE "main_core" bounds:D3-E4 {
    STAIR width:1.2m
    LIFT capacity:8
    SHAFT type:MEP
}

Available Room Types¶

Habitable Spaces¶

Type	Aliases	Min Area	Furniture
BEDROOM	BED, BILIK_TIDUR, BILIK_UTAMA	6.5 m²	Bed, side table
KITCHEN	DAPUR	4.6 m²	Counter, sink
LIVING	RUANG_TAMU	6.5 m²	Sofa, table
DINING	RUANG_MAKAN	6.5 m²	Table, chairs
OFFICE	PEJABAT	9.0 m²	Desk, chair
CLASSROOM	BILIK_DARJAH	46.5 m²	Desks, sprinklers
CANTEEN	KANTIN	30.0 m²	Tables, sprinklers

Service Spaces¶

Type	Aliases	Min Area	Fixtures
BATHROOM	BILIK_MANDI	2.5 m²	Toilet, sink, exhaust
TOILET_BLOCK	TANDAS	2.5 m²	Toilet, sink
STORAGE	STOR	0 m²	—

Circulation Spaces¶

Type	Aliases	Min Width
CORRIDOR	HALL	1.8m (educational)
LOBBY	FOYER	3.0m
WAITING	—	3.0m

Combined Spaces¶

Type	Description
OPEN_PLAN	Combined zones — no internal walls between zones
PORCH	Covered entry — partial walls (exterior open)

BOM Resolution¶

The compiler automatically calculates element quantities from room type, area, and building code rules.

How It Works¶

ROOM "kantin" [CANTEEN] 84.0m²
    7x pendent         ceil(84.0m² / 12.1) = 7 (NFPA_13 8.6.2.1)
    2x Supply Diffuser ceil(CFM / 600) = 2 (ASHRAE_62_1)
    6x Downlight       ceil(84.0m² x 200 lux / 3000 lm) = 6 (MS_1525)
    9x Canteen Table   ceil(occupancy / 4) = 9 (IBC 1004.5)

Calculation Rules¶

Rule	Formula	Code Reference
PER_AREA	`ceil(area / base)`	NFPA 13 (sprinklers)
PER_LUX	`ceil(area x lux / lumens)`	MS 1525 (lighting)
PER_CFM	`ceil(cfm / base)`	ASHRAE 62.1 (diffusers)
PER_OCCUPANT	`ceil(occupancy / base)`	IBC (furniture)
FIXED	`base`	IPC 403.1 (fixtures)

BOM Types¶

Type	Description	Example
MANDATORY	Always required	Toilet in BATHROOM
OPTIONAL	User-specified	Bidet (future)
VARIABLE	Calculated from room properties	Sprinklers, lights, tables

Adding a New Recipe¶

New BOM recipes require only SQL — no Java changes:

INSERT INTO m_bom (bom_id, m_product_category_id, is_active)
VALUES ('STUDY_DESK_SET', 'FR', 1);  -- FR = Furniture category

INSERT INTO m_bom_line (bom_id, role, child_name_pattern, sequence, is_active)
VALUES ('STUDY_DESK_SET', 'DESK', 'Desk%', 1, 1);

LOD400 Library Integration¶

The compiler uses LOD400 (fabrication-ready) tessellated geometry from the component library (library/component_library.db).

How Geometry Binds to Elements¶

Every placed element goes through the MeshBinder which: 1. Looks up LOD400 geometry from ComponentLibrary.resolveGeometryByInstance() 2. Validates scale factors are within [0.3, 3.0] per axis 3. Creates a BoundElement — a proof-carrying type that certifies the mesh fits the bounding box 4. Tracks violations as degradations reported with [WITNESS] tags

All four buildings route through MeshBinder — there is a single unified geometry path.

Geometry Provenance¶

Each geometry entry in I_Geometry_Map has a provenance:

Provenance	Meaning
LIBRARY	Mesh from component library (LOD400 tessellation)
EXTRACTED	Mesh extracted from reference IFC
PARAMETRIC	Mesh generated from parameters (future)

Library Coverage¶

Element	Library Items	Coverage
Doors	46 families	100%
Windows	58 families	88%
Stairs	1	100%
Furniture	11 types	100%
Lights	85 types	100%
Sprinklers	84 types	100%
MEP Pipes	Generated	100%

Library Statistics¶

sqlite3 library/component_library.db "
  SELECT COUNT(*) AS total_components FROM component_definitions;
  SELECT COUNT(*) AS total_geometries FROM base_geometries;
  SELECT COUNT(*) AS ad_tables FROM sqlite_master
    WHERE type='table' AND name LIKE 'ad_%';"

Current: 8,766 component definitions, 55 ad_* tables, 23,888 metadata rows.

Profiles and Building Codes¶

Using a Profile¶

BUILDING "Rumah Rakyat" profile:"Malaysian_Residential" { ... }

Profiles select wall types, beam sizes, door families, and furniture sets from the metadata catalog. Adding a new profile requires only SQL INSERT statements — no Java changes.

Available Profiles¶

Profile	Tradition	Wall Thickness	Storey Height
`UK_Residential`	UK brick-cavity	290mm	3.3m
`US_Residential`	US frame-with-siding	417mm	2.4m
`Malaysian_Residential`	MY brick-plaster	150mm	2.8m
`Malaysian_Institutional`	MY institutional	150mm	4.0m

Two-Pass Resolution¶

All metadata lookups are profile-aware: 1. Pass 1: Search for rules matching the specific profile 2. Pass 2: Fall back to generic rules (profile = NULL)

Profile-specific rules automatically override generic rules.

Vocabulary Mapping (Malaysian)¶

Input	Maps To
BILIK_UTAMA	MASTER_BEDROOM
BILIK_TIDUR	BEDROOM
DAPUR	KITCHEN
RUANG_TAMU	LIVING
BILIK_MANDI	BATHROOM
KANTIN	CANTEEN

Fire Protection¶

Automatic Triggers¶

Trigger	Threshold	Action
Building height	> 18m	Sprinklers required
Floor area	> 1000m²	Sprinklers required
Occupancy	Assembly, High-rise	Sprinklers required

Compliance Modes¶

Mode	Behavior
(none)	No automatic fire protection
AUTO_FP	Generate sprinklers when triggered
FULL_COMPLIANCE	All code requirements enforced

Suppression Piping¶

When sprinklers are generated, the compiler creates the pipe network:

RISER (100mm) -- MAIN (65mm) -- BRANCH (25mm) --> SPRINKLER_HEAD

Pipe sizing follows NFPA 13 (Light Hazard).

Output Formats¶

Database Schema (SQLite)¶

Table	Purpose
`spatial_structure`	Building hierarchy (Project > Site > Building > Storey)
`elements_meta`	Element metadata: guid, ifc_class, name, storey, discipline, material_name, material_rgba
`elements_rtree`	Spatial index: id, minX, maxX, minY, maxY, minZ, maxZ
`base_geometries`	Shared geometry (vertices/faces BLOBs, float32/int32 arrays)
`element_geometry`	Per-element geometry hash link
`element_transforms`	Per-element world position (center_x/y/z)
`surface_styles`	Material rendering properties (transparency, specularity)
`assembly_components`	BOM parent-child relationships
`mep_systems`	MEP system definitions
`system_nodes` / `system_edges`	MEP system graph
`simple_qto`	Quantity takeoff (area, volume, length)

Output Location¶

All output goes to DAGCompiler/lib/output/:

File	Description
`ifc4_samplehouse.db`	SampleHouse compiled output
`ifc2x3_duplex.db`	Duplex compiled output
`sjtii_terminal.db`	Terminal compiled output
`tb_lktn.db`	TB-LKTN compiled output

Viewing Output¶

The primary viewer is the Bonsai Federation addon in Blender, which reads output SQLite DBs directly — loading geometry, materials, and transparency from the database.

Material and Colour Data¶

What's in the Output¶

Each element in elements_meta can have:

Column	Description	Example
`material_name`	IFC material name	`Glass`, `Concrete Block`
`material_rgba`	RGBA colour (0.0-1.0)	`0.000,0.502,0.753,0.100`

RGBA Format¶

R,G,B,A values, each 0.0-1.0. Alpha = opacity (1.0 = opaque, 0.0 = transparent). Example: 0.000,0.502,0.753,0.100 = blue glass, 10% opaque.

Transparency Pipeline¶

Transparent elements (glass, shower screens) require both: 1. elements_meta.material_name matching a surface_styles.style_name 2. The surface_styles table (copied from component library during compilation)

Key transparent styles:

Style	Transparency	Use
`Glass`	0.9	Windows, curtain wall
`Window_W1`	0.6	TB-LKTN standard windows
`Shower`	0.3	Shower screens

Querying Materials¶

-- All materials in output
SELECT material_name, COUNT(*), material_rgba
FROM elements_meta WHERE material_name IS NOT NULL
GROUP BY material_name;

-- Glass elements with transparency
SELECT guid, material_name, material_rgba
FROM elements_meta WHERE material_name = 'Glass';

Validation and Proofs¶

PlacementProver (14 Proofs)¶

After compilation, PlacementProver.java runs 14 mathematical proofs in 5 tiers:

Tier	Proofs	What It Checks
1	P01-P04	Per-element arithmetic (positive dimensions, valid coordinates)
2	P05-P06	Pairwise relations (no identical overlaps, adjacency)
3	P07-P09	Host-element containment (door within wall, fixture within room)
4	P10-P12	Topological closure (walls form enclosure, rooms bounded)
5	P13-P14	Conservation laws (grid coverage, slab continuity)

The prover is non-blocking — it reports violations but never prevents emission. The spatial X-ray score remains the ultimate arbiter.

BoundElement (Dimensional Contract)¶

Every element bound to library geometry passes through BoundElement, which enforces: - Mesh fits within bounding box - Scale factors within [0.3, 3.0] per axis - Violations tracked as degradations and reported as [WITNESS] entries

GeometryIntegrityChecker¶

Validates mesh quality: - Vertex-to-bbox containment (all vertices within element bounds) - Mesh topology (manifold, closed surfaces) - Vertex/face count consistency

SpatialDigest (Determinism)¶

Computes SHA-256 hash of all element bounding boxes at 1mm precision. Same input must always produce the same digest — this detects non-deterministic compilation.

Dimension Range Validation (DV010)¶

When onboarding a new IFC file, the pipeline checks every extracted element's dimensions (W, D, H) against typical ranges mined from 20 real buildings (415 rules, 25 IFC classes, stored in ERP.db).

The check runs automatically as a pre-flight in the IFC-to-BOM pipeline:

IFC → extract.py → ExtractionPopulator → DimensionRangeValidator → BOM builders

What it flags: Elements whose dimensions deviate by more than 5× from observed ranges across all onboarded buildings. For example: - IfcWall typical width: 800–10,269mm across 20 buildings - A 95mm partition wall → flagged (thin but legitimate) - A 500,000mm wall → flagged (data error)

Advisory only — outliers are logged but never block the pipeline:

[DimRange] MyBuilding: 120/120 checked, 115 PASS, 5 outliers
[DimRange]   IfcWall: 2 outlier(s)
[DimRange]     Wall-Partn: W=95mm (range [800-10269]mm)

The same mined rules also feed the PlacementValidator in the BIM Designer, providing dimension sanity checks during interactive design.

To apply new mined rules after onboarding additional buildings:

./scripts/apply_mined_rules.sh           # uncomment + apply all DV_*_rules.sql
./scripts/apply_mined_rules.sh --dry-run  # preview without changes

Spatial Scoring (X-Ray)¶

Current Scores¶

Building	Recall	Precision	F1	Elements
SampleHouse	100%	100%	100%	—
Duplex	100%	100%	100%	1,085
Terminal	~100%	100%	~100%	51,088
TB-LKTN	N/A (generative)	N/A	N/A	58

How It Works¶

The spatial X-ray compares dimension signatures between compiled output and reference:

signature = (category, L_mm, W_mm, H_mm)

Dimensions are sorted descending and bucketed to 10mm. Two matching modes: - Exact match: identical signature tuple - Near match: 5mm tolerance on thin dimension, 10% tolerance on larger dimensions

Running the Checker¶

python3 DAGCompiler/python/spatial_checker.py \
  DAGCompiler/lib/output/ifc4_samplehouse.db \
  DAGCompiler/lib/input/Ifc4_SampleHouse_extracted.db \
  --discipline ARC

The --discipline ARC flag filters to architectural elements only, preventing MEP elements from drowning the architectural signal.

MEP System Queries¶

List All MEP Systems¶

sqlite3 DAGCompiler/lib/output/tb_lktn.db "SELECT * FROM mep_systems"

View Drainage Paths¶

SELECT n1.name AS from_element, e.edge_type, n2.name AS to_element
FROM system_edges e
JOIN system_nodes n1 ON e.from_node_id = n1.node_id
JOIN system_nodes n2 ON e.to_node_id = n2.node_id
WHERE e.edge_type = 'DRAINS_TO'

Troubleshooting¶

"Unknown space type"¶

The room type is not in the metadata. Check available types:

sqlite3 library/component_library.db "SELECT name FROM ad_space_type"

"BOM exceeds capacity"¶

The outlier log shows when calculated quantities don't fit:

[OUTLIER] canteen_table | CANTEEN "kantin" (8.0m x 8.0m)
  --> BOM wants 10 tables but only 6 fit (grid 2x3)

Solution: increase room size or accept the reduced quantity.

Placement mode toggle¶

If scores drop unexpectedly, check the placement mode:

sqlite3 library/component_library.db \
  "SELECT * FROM ad_sysconfig WHERE config_key='placement_mode'"

Toggle: UPDATE ad_sysconfig SET config_value='FLAT' WHERE config_key='placement_mode'

Witness claim FAILED¶

Check the specific claim in console output. Witness failures are non-blocking — the building still compiles, but the proof didn't hold. Investigate the reported coordinates.

Quick Reference¶

# Build
mvn compile -q

# Compile all 4 buildings
mvn exec:java -pl DAGCompiler -Dexec.mainClass="com.bim.compiler.dsl.SampleHouseEndToEndTest" -q
mvn exec:java -pl DAGCompiler -Dexec.mainClass="com.bim.compiler.dsl.TBLKTNDuplexEndToEndTest" -q
mvn exec:java -pl DAGCompiler -Dexec.mainClass="com.bim.compiler.dsl.TerminalEndToEndTest" -q
mvn exec:java -pl DAGCompiler -Dexec.mainClass="com.bim.compiler.dsl.TBLKTNEndToEndTest" -q

# Spatial fidelity check
python3 DAGCompiler/python/spatial_checker.py \
  DAGCompiler/lib/output/ifc4_samplehouse.db \
  DAGCompiler/lib/input/Ifc4_SampleHouse_extracted.db \
  --discipline ARC

# Query element count
sqlite3 DAGCompiler/lib/output/ifc4_samplehouse.db \
  "SELECT ifc_class, COUNT(*) FROM elements_meta GROUP BY ifc_class"

# Query materials
sqlite3 DAGCompiler/lib/output/ifc4_samplehouse.db \
  "SELECT material_name, material_rgba FROM elements_meta WHERE material_name IS NOT NULL"

Document	Purpose
`SourceCodeGuide.md`	Developer onboarding, pipeline internals, data provenance
`ARCHITECTURE.md`	Governing architecture document (v3.0)
`TheRosettaStoneStrategy.md`	Validation methodology and scoring
`PREFAB_ARCHITECTURE.md`	Assembly hierarchy and MANIFEST contracts
`RELATIONAL_PLACEMENT_SPEC.md`	Relational placement migration spec
`HARDCODE_AUDIT.md`	Hardcoded values audit (33 findings)
`BUNDLE_WORKER_FRAMEWORK.md`	BundleWorker interface and slot dispatch
`witness-system-specification.md`	Witness proof system design
`BIM_Designer.md`	Compliance layer + Bonsai addon vision
`CurrentState.txt`	Known issues for expert review
`WHITEPAPER.pdf`	Academic paper (v1.0 — scores being updated)

BIM Compiler User Guide¶

Table of Contents¶

Quick Start¶

Minimal Example¶

Compile and Verify¶

Building and Running¶

Prerequisites¶

Build from Source¶

The Four Buildings¶

Run Commands¶

Output¶

DSL Syntax Reference¶

Overall Structure¶

GRID Definition¶

Room/Space Declaration¶

Constraint Keywords¶

OPEN_PLAN (Combined Zones)¶

Door and Window Specifications¶

CORE Block (Vertical Circulation)¶

Available Room Types¶

Habitable Spaces¶

Service Spaces¶

Circulation Spaces¶

Combined Spaces¶

BOM Resolution¶

How It Works¶

Calculation Rules¶

BOM Types¶

Adding a New Recipe¶

LOD400 Library Integration¶

How Geometry Binds to Elements¶

Geometry Provenance¶

Library Coverage¶

Library Statistics¶

Profiles and Building Codes¶

Using a Profile¶

Available Profiles¶

Two-Pass Resolution¶

Vocabulary Mapping (Malaysian)¶

Fire Protection¶

Automatic Triggers¶

Compliance Modes¶

Suppression Piping¶

Output Formats¶

Database Schema (SQLite)¶

Output Location¶

Viewing Output¶

Material and Colour Data¶

What's in the Output¶

RGBA Format¶

Transparency Pipeline¶

Querying Materials¶

Validation and Proofs¶

PlacementProver (14 Proofs)¶

BoundElement (Dimensional Contract)¶

GeometryIntegrityChecker¶

SpatialDigest (Determinism)¶

Dimension Range Validation (DV010)¶

Spatial Scoring (X-Ray)¶

Current Scores¶

How It Works¶

Running the Checker¶

MEP System Queries¶

List All MEP Systems¶

View Drainage Paths¶

Troubleshooting¶

"Unknown space type"¶

"BOM exceeds capacity"¶

Placement mode toggle¶

Witness claim FAILED¶

Quick Reference¶

Further Reading¶
